DG-BG4300NU User
Manual
27
The following table describes the parameters in this page:
Field Description
VPI
Virtual path identifier (VPI) is the virtual path between two points in an
ATM network. Its valid value is in the range of 0 to 255. Enter the correct
VPI provided by your ISP. By default, VPI is set to 0.
VCI
Virtual channel identifier (VCI) is the virtual channel between two points
in an ATM network. Its valid value is in the range of 32 to 65535. (0 to 31
is reserved for local management of ATM traffic) Enter the correct VCI
provided by your ISP. By default, VCI is set to 35.
After the setting is done, click Next, the page as shown in the following figure appears.
There are five WAN connection types: PPP over ATM (PPPoA), PPP over Ethernet (PPPoE),
1483 MER, 1483 Routed and 1483 Bridged. The below mentioned topics describe the
modes.
