C
HAPTER
19
| MAC Address Security
Static MAC Addresses
– 106 –
WEB INTERFACE
To display the MAC address forwarding table, click Security, MAC Address,
MAC Forwarding Table.
Figure 37: MAC Address Forwarding Table
STATIC MAC ADDRESSES
A static address can be assigned to a specific interface on the switch. Static
addresses are bound to the assigned interface and will not be moved.
When a static address is seen on another interface, the address will be
ignored and will not be written to the address table.
PARAMETERS
The following parameters are displayed on the Static MAC page:
◆ MAC Address — Physical address of a device mapped to an interface.
◆ VLAN ID — The ID of a configured VLAN (1-4094).
◆ Port — Port or trunk associated with the device that is assigned as a
static address.
WEB INTERFACE
To configure static MAC addresses:
1. Click Security, MAC Address, Static MAC.
2. Specify the MAC address to be statically assigned.
3. Specify the VLAN ID.
4. Select the port or trunk interface for the static assignment.
5. Click Add.
