Digisol DG-GS1526 - Figure 39: MAC Address Filtering

C HAPTER 19 | MAC Address Security
MAC Address Filtering
– 108 –
WEB INTERFACE
To configure MAC Address Filtering:
1. Click Security, MAC Address, MAC Address Filtering.
2. Specify the MAC address to be filtered.
3. Specify the VLAN ID.
4. Select to filter the MAC address as the source, destination, or both.
5. Set a name to describe the filter.
6. Click Add.
Figure 39: MAC Address Filtering
