C
HAPTER
10
| Spanning Tree
Configuring STP Port Settings
– 78 –
◆ Edge — The Edge setting for the port:
■
Config — The administrator configured Edge setting.
■
Actual — This parameter is initialized to the port setting for Edge
(that is, True or False), but will be set to false if a BPDU is received,
indicating that another bridge is attached to this port.
WEB INTERFACE
To configure port settings for Spanning Tree:
1. Click Configuration, Spanning Tree, STP Port Setting.
2. Modify the required attributes for one or a group of ports.
3. Click Apply.
Figure 23: STP Port Setting
