C
HAPTER
6
| Link Aggregation
Configuring Trunk Settings
– 53 –
■
Dest. IP – All traffic with the same source and destination IP
address is output on the same link in a trunk. This mode works best
for switch-to-router trunk links where traffic through the switch is
destined for many different hosts. Do not use this mode for switch-
to-server trunk links where the destination IP address is the same
for all traffic.
WEB INTERFACE
To configure a trunk’s load-balancing settings:
1. Click Configuration, Aggregation Link, Trunk Setting.
2. Select the trunk group ID to be configured or modified.
3. Selec the trunk Distribution Algorithm Parameters as required.
4. Click Apply.
Figure 13: Trunk Distribution Algorithm Setting
