DG-PS1010U User Manual
7
Dimension: 73 x 64 x 28 mm
Weight: 58g
Features
Easy-to-use Setup Wizard
Network protocol support (TCP/IP, IPX/SPX, NetBEUI, Apple Talk, LPR, RAW
TCP/IP, SMB over TCP/IP)
DHCP Client Support
Windows Print Monitor Technology
Internet Printing Protocol (IPP) support
SNMP & HP Web JetAdmin Support
Firmware upgrade
LED Indicators
LED State Indication
Status
Blinking for POST
(Orange)
When power switched on, the Status indicator will flash five
times, and then on.
100Mbps On (Green) LAN Port has a valid network connection at 100Mbps.
10Mbps On (Orange) LAN Port has a valid network connection at 10Mbps.
On (Green) Connect with USB2.0 printer
USB
On (Orange) Connect with USB1.1 printer
System Requirements
One Windows-based desktop/notebook with CD-ROM drive and 50Mb of Hard Disk space
One USB printer
One USB printer cable (provided with your printer)
One HUB/Switch for connecting Print Server to the Network
