DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
14
External Interface
Specification
Videointerfaces CRT1, LCD for TFT and STN
USB V1.1 Not available
LPT1: Internal
COM1: RS232
COM2: RS232
COM3: RS232
COM4: RS232
Keyboard: PS/2
Mouse: PS/2
Floppy: 26pin FCC Interface for TEAC Minifloppy
Harddisk: 1 channel 44pin RM2.0mm ATAIDE-cable
Speaker: 0.1Watt Speaker
Powersupply:
Input: Nom. 5V Tolerance +/- 3%
Protection: Not integrated, EMI filtered must be added external
Spec.
Power Consumption
Specification
At 5V Typical 1.5 Amp.
Standby Not available
Poweroff 0mA
Physical Characteristics
Specification
PC/104
Dimensions: Length: 91mm
Depth: 96mm
Height: 25mm
Weight: 170gr
Operating Environment
Specification
Relative Humidity: 5 - 90% non condensing
IEC68-2-30 at -20° to +50°C operating
Vibration operating: IEC68-2-6 10-50Hz, 0.075mm and 55-500Hz, 1.0G
Vibration nonoperating: IEC68-2-6 10-50Hz, 0.15mm and 55-500Hz, 2.0G
Shock operating: IEC68-2-27 10G, 11ms ½ sine
Shock nonoperating: IEC68-2-27 50G, 11ms, ½ sine
Altitude IEC68-2-13 4571meter operating
Temperature operating
IEC68-2-1,2,14: Standard -20°C to +60°C
Extended Temp. option MIL-810-501/502 Extended temperatur -40°C to +85°C
Temperature storage
IEC68-2-1,2,14: -65°C to +125°C *)
*) The backupbattery is limited on –40°C to +85°C operating and storage temperature !
