DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
15
EMI / EMC Tests
Specification
If all signals are externaly filtered and assembled into a closed metalic case !
EMC emission EN61000-6-2:2001
Conducted disturbance EN55022 Class B
Radiated disturbance EN55022 Class B
EMC immunity EN61000-6-2
Electrostatic discharge (ESD) EN61000-4-2
Voltage = 4kV contact / 8kV air
Criteria A
Radiated RF-Field EN61000-4-3
Level = 10V/m
Criteria A
Electrical fast transients (Burst) EN61000-4-4
Grade 2: DC-Powerlines = 1000V (5/50ns)
Grade 2: AC-Powerlines = 2000V (5/50ns)
Grade 2: Signallines = 500V (5/50ns)
Criteria B
Surge EN61000-4-5
Grade 2: DC-Powerlines = 1kV, (1.2/50us)
Grade 2: AC-Powerlines = 2kV, (1.2/50us)
Criteria B
Conducted disturbances EN61000-4-6
Voltage = 10V coupled by case
Criteria A
Security:
e1: Not planed
UL Not planed
ETS 301 Not planed
CE/SEV Yes
Safety AR385-16
Any information is subject to change without notice.
