DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
84
X3 LAN LED
Pin Signal Remarks
1 LILEDX / Link LED 330 Ohm resistor on board
2 VCC3
3 ACTLEDX / Activity LED 330 Ohm resistor on board
X2 JTAG connector (debugging)
Pin Signal Pin Signal
1 GND 2 VCC
3 TCK 4 CMDACK
5 TMS 6 BREAK
7 TDI 8 STOP
9 TDO 10 TRACE
11 TRST 12 RESETIN
X1 Spare connector (not assembled), for test purposes only
Pin Signal Pin Signal
1 PD0 2 PD1
3 PD2 4 PD3
5 PD4 6 PD5
7 PD6 8 PD7
9 PD8 10 PD9
11 PD10 12 PD11
13 PD12 14 PD13
15 PD14 16 PD15
17 PA0 18 PA1
19 PA2 20 ICEDISABLE
21 PBREQ 22 TV
23 PBGNT 24 PRW
25 TCLK 26 WENABLE
27 WSTR 28 WDENA
29 CLKTEST 30 GND
J60 Ext. HDD Led, (new since V2.2)
Pin Signal Pin Signal
1 Vcc 2 HDD
