DIGITAL-LOGIC AG MSM586SEN/SEV Manual V1.5E
86
B1 Battery connector
Pin Signal
Pin 1 Battery 3.6V
Pin 2 Ground
U112 DOC 2000 IC- socket
Pin Signal Pin Signal
1 NC 17 D3
2 A16 18 D4
3 A15 19 D5
4 A12 20 D6
5 A7 21 D7
6 A6 22 CE#
7 A5 23 A10
8 A4 24 OE#
9 A3 25 A11
10 A2 26 A9
11 A1 27 A8
12 A0 28 A13
13 D0 29 A14
14 D1 30 NC
15 D2 31 WE#
16 GND 32 VCC
U96 Compact card holder, typ1
Pin Signal
Pin 01 = GND
Pin 02 = D3
Pin 03 = D4
Pin 04 = D5
Pin 05 = D6
Pin 06 = D7
Pin 07 = CS0 (active low)
Pin 08
= (A10) NC
Pin 09 = GND
Pin 10
= (A9) NC
Pin 11
= (A8) NC
Pin 12
= (A7) NC
Pin 13 = Vcc
Pin 14
= (A6) NC
Pin 15
= (A5) NC
Pin 16
= (A4) NC
Pin 17
= (A3) NC
Pin 18 = ADR2
Pin 19 = ADR1
Pin 20 = ADR0
Pin 21 = D0
Pin 22 = D1
Pin 23 = D2
Pin 24 = IOCS16 (active low)
Pin 25
= (CD2) NC
Pin 26
= (CD1) NC
Pin 27 = D11
