Pin Signal
Pin 28 = D12
Pin 29 = D13
Pin 30 = D14
Pin 31 = D15
Pin 32 = CS1 (active low)
Pin 33
= (Vs1) NC
Pin 34 = IOR (active low)
Pin 35 = IOW (active low)
Pin 36 = Vcc
Pin 37 = IRQ
Pin 38 = Vcc
Pin 39 = CEL
Pin 40
= (VS2) NC
Pin 41 = Reset (active low)
Pin 42 = IOCHRDY (active low)
Pin 43
= (INPACK-) NC
Pin 44 = Vcc
Pin 45 = LED (active low)
Pin 46 = PDIAG
Pin 47 = D8
Pin 48 = D9
Pin 49 = D10
Pin 50 = GND
Pin 25 Pin 1
Pin order
(solder view)
Pin 50 Pin 26
