APPENDIX B: SUPPORTED SIGNAL INPUT MODES
Rev A June 2017
SDI formats
Timing
SDI Link
mode
Signal Standards
Color
Encode
Sampling
Structure
Bit
Depth
Remark
NTSC SD SMPTE 259M-C
270Mbps SD
YCbCr 4:2:2 10 128M
PAL SD SMPTE 259M-C
270Mbps SD
YCbCr 4:2:2 10 128M
1035i60 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080i59 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080i60 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080P30 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080P25 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080i50 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080P24 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
720P60 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
720P50 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080Sf25 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080Sf30 HD SMPTE 292M 1.5Gbps
HD
YCbCr 4:2:2 10 128M
1080P50 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
1080P59 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
1080P60 3G Level A SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
1080P50 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
1080P59 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
1080P60 3G Level B SMPTE 424M 3Gbps YCbCr 4:2:2 10 128M
Notes
