3D menu
Use this menu to enable, disable and set up 3D input, as follows:
• 3D Format — Off, Auto, Dual Pipe and Frame Sequential.
Frame Sequential is displayed at the incoming rate whereas Dual Pipe interleaves
the input to display up to 120 Hz.
• DLP Link — Off / On.
DLP Link On emits a sync pulse for the 3D glasses via the projected image.
DLP Link Off will send the sync pulse to the sync out connector to use with an
external third party emitter.
• Eye Swap — Normal and Reverse (set to Reverse if the left- and right-eye images
are displayed in the wrong order)
• Dark Time — 0.65 ms, 1.3 ms and 1.95 ms. Set to reduce the effect of images
overlapping while the glasses are switching.
3D Sync
• Offset — use the LEFT and RIGHT arrow buttons to compensate for signal
processing delays in the projector.
• Reference— External and Internal.
Notes
3D video is only possible on the
HDMI 3 and HDMI 4 inputs.
While the projector is in 3D mode,
the OSD is unavailable. Settings
can be accessed via web pages
served from the projector. For
more information, see Served Web
Pages.
If 3D Format is set to Off, all other
3D settings will be unavailable.
For further information about
supported 3D formats, see 3D
connections in the Connection
Guide.
When 3D is on, the following
settings become unavailable:
• Image > Smooth Picture,
Brightness, Contrast,
Saturation, Hue, Sharpness,
Noise Reduction, Freeze,
Resync.
• Color > Color Space.
• Geometry > Aspect Ratio,
Digital Zoom, Overscan.
• Setup > Screen Setting,
Auto Source, Trigger-1,
Trigger-2.
• PIP > all settings.
See also 3D types and Some 3D
settings explained further in this
guide.
See Appendix B: Supported
Signal Input Modes > 3D formats
in the Reference Guide for 3D
resolutions and frame rates.
3D
DLP Link
Eye Swap
3D Format
Dark Time
Off
Normal
Auto
1.95 ms
Reference
Offset
Internal
100
3D Sync
