page iv
Digital Projection E-Vision Laser 4K Series
Rev A June 2017
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
Voltage selection ................................................................................... 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
Control panel ......................................................................................... 6
Projector indicators ................................................................................ 7
REMOTE CONTROL ....................................................................... 8
Infrared reception ................................................................................ 11
POSITIONING THE SCREEN AND PROJECTOR ........................... 12
Roll and pitch ...................................................................................... 13
CHANGING THE LENS ................................................................. 14
Inserting a new lens ............................................................................ 14
Removing the lens .............................................................................. 14
OPERATING THE PROJECTOR .................................................... 15
Switching the projector on ................................................................... 15
Switching the projector off ................................................................... 15
Selecting an input signal ..................................................................... 16
Selecting a test pattern ....................................................................... 16
Adjusting the lens ................................................................................ 17
Adjusting the image............................................................................. 17
CONNECTION GUIDE ............................................................................19
SIGNAL INPUTS .......................................................................... 21
Digital inputs and outputs .................................................................... 21
EDID on the DisplayPort, HDMI and HDBaseT inputs ........................ 22
Using DisplayPort/HDMI/HDBaseT switchers with the projector ........ 22
3D connections ................................................................................... 23
Frame sequential 1080p and WUXGA 3D sources at 100 and 120 Hz ............... 23
Dual Pipe 1080p, WUXGA and WQXGA 3D sources at 100 and 120 Hz ............ 23
3D Sync............................................................................................... 24
3D Sync In ......................................................................................... 24
3D Sync Out ....................................................................................... 24
3D Sync IR ........................................................................................ 24
CONTROL CONNECTIONS ........................................................... 25
LAN connection examples .................................................................. 26
RS232 connection example ............................................................... 27
