PIP menu
• PIP
Turn PIP on and off.
• Source
Select an input source for the PIP image.
Any combinations are possible between main and PIP input source, as long as one of
the inputs is either DisplayPort or 3G-SDI.
• Position
Set the location of the PIP image on the screen. Choose from Top-Left, Top-Right,
Bottom-Left, Bottom-Right and PBP.
Notes
PIP functionality is not available with
inputs HDMI 3 and HDMI 4.
PIP
Source
Position
PIP
HDMI1
Top-Left
Off
