Digital Projection E-Vision Laser 4K Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev A June 2017
Roll and pitch
The projector can be operated in numerous positions.
In portrait mode, it is recommended to position the projector with inputs facing upward, as shown in the diagram.
1
Recommended positions: inputs side up
2
Also possible
Notes
Pitch
360°
2
30°
330°
2
1
Roll
