Digital Projection E-Vision Laser 4K Series - RS232 Connection Example

page 27
Digital Projection E-Vision Laser 4K Series
Connection Guide
CONTROL CONNECTIONS
Rev A June 2017
RS232 connection example
All of the projector’s features can be controlled via a serial connection, using commands described in the Protocol Guide.
Notes
The Protocol Guide is available
separately.
Projector
Computer
Straight-
through cable
1
1
RS232
HDBaseT/LAN Ethernet
SDI IN SDI OUT
3D SYNC IR
TRIGGER
(1) (2) RS232
WIRED REMOTE
HDMI
1
HDMI
2
HDMI
3
HDMI
4
SYNC IN SYNC OUT
DisplayPort
