Digital Projection E-Vision Laser 4K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev A June 2017
Projector Overview
Front and rear views
1
Air inlet
2
Front infrared window and indicators
3
Air inlet
4
Lens mount
5
Rear infrared window
6
Air outlet
7
Connections panel
8
Control panel
9
Adjustable feet
10
Voltage selector
11
Mains socket and switch
12
Air inlets
Front view
4
3
2
1
Rear view
9
8
5
76
1110
Bottom view
12
Notes
