Digital Projection E-Vision Laser 4K Series
Installation and Quick-Start Guide
CONNECTING THE POWER SUPPLY
Rev A June 2017
Connecting The Power Supply
Adjust the VOLTAGE SELECT switch
1
to the required voltage, then rmly push the mains connector into the socket
2
.
Voltage selection
The VOLTAGE SELECT switch must be set to match the power supply you are using:
Voltage of power supply used Position of VOLTAGE SELECT switch
AC100-130V outlet
AC200-240V (single phase) outlet
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.
1
2
