DLP Projector—User’s Manual
— 74 —
Command Group 02
ASCII HEX Function Description Return Value
VXXS0209 56h Xh Xh 53h 30h 32h 30h 39h 0Dh
Select HDMI 2
(MEDIA)
P/F
VXXS0210 56h Xh Xh 53h 30h 32h 31h 30h 0Dh
Select
Display Port
P/F
VXXS0211 56h Xh Xh 53h 30h 32h 31h 31h 0Dh Select Multi Media P/F
VXXG0220 56h Xh Xh 47h 30h 32h 32h 30h 0Dh
Get Current
Source
Return
1:RGB
2:RGB2
3:DVI
4:Video
5:S-Video
6:HDMI 1
7:BNC
8:Component
9:HDMI 2
10:Display Port
11:Multi Media.
Pn/F
Command Group 03
ASCII HEX Function Description Return Value
VXXG0301 56h Xh Xh 47h 30h 33h 30h 31h 0Dh Get Scaling
0:Fill
1:4:3
2:16:9
3:Letter Box
4:Native
5:2.35:1
Pn/F
VXXS0301n 56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh Set Scaling
0:Fill
1:4:3
2:16:9
3:Letter Box
4:Native
5:2.35:1
P/F
VXXG0302 56h Xh Xh 47h 30h 33h 30h 32h 0Dh Blank Pn/F
VXXS0302n 56h Xh Xh 53h 30h 33h 30h 32h nh 0Dh Blank P/F
VXXG0303 56h Xh Xh 47h 30h 33h 30h 33h 0Dh Auto Keystone On Pn/F
VXXS0303n 56h Xh Xh 53h 30h 33h 30h 33h nh 0Dh Auto Keystone On P/F
VXXG0304 56h Xh Xh 47h 30h 33h 30h 34h 0Dh Freeze On Pn/F
VXXS0304n 56h Xh Xh 53h 30h 33h 30h 34h nh 0Dh Freeze On P/F
VXXG0305 56h Xh Xh 47h 30h 33h 30h 35h 0Dh Volume n=0~10 Pn/F
VXXS0305n 56h Xh Xh 53h 30h 33h 30h 35h nh 0Dh Volume n=0~10 P/F
VXXG0306 56h Xh Xh 47h 30h 33h 30h 36h 0Dh Treble n=0~16 Pn/F
VXXS0306n 56h Xh Xh 53h 30h 33h 30h 36h nh 0Dh Treble n=0~16 P/F
VXXG0307 56h Xh Xh 47h 30h 33h 30h 37h 0Dh Bass n=0~16 Pn/F
VXXS0307n 56h Xh Xh 53h 30h 33h 30h 37h nh 0Dh Bass n=0~16 P/F
VXXG0308 56h Xh Xh 47h 30h 33h 30h 38h 0Dh Projection Mode
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling
Pn/F
