Command Group 03
ASCII HEX Function Description Return Value
VXXS0308n 56h Xh Xh 53h 30h 33h 30h 38h nh 0Dh Projection Mode
0:Front
1:Rear
2:Ceiling
3:Rear+Ceiling
P/F
VXXG0309 56h Xh Xh 47h 30h 33h 30h 39h 0Dh
Set vertical
keystone value
n=-40~+40 Pn/F
VXXS0309n 56h Xh Xh 53h 30h 33h 30h 39h nh 0Dh
Set vertical
keystone value
n=-40~+40 P/F
VXXG0310 56h Xh Xh 47h 30h 33h 31h 30h 0Dh
Set horizontal
keystone value
n=-20~+20 Pn/F
VXXS0310n 56h Xh Xh 53h 30h 33h 31h 30h nh 0Dh
Set horizontal
keystone value
n=-20~+20 P/F
VXXG0311 56h Xh Xh 47h 30h 33h 31h 31h 0Dh Adjust the zoom n=-10~+10 Pn/F
VXXS0311n 56h Xh Xh 53h 30h 33h 31h 31h nh 0Dh Adjust the zoom n=-10~+10 P/F
VXXG0312 56h Xh Xh 47h 30h 33h 31h 32h 0Dh Adjust the focus n=-20~+20 Pn/F
VXXS0312n 56h Xh Xh 53h 30h 33h 31h 32h nh 0Dh Adjust the focus n=-20~+20 P/F
VXXG0313 56h Xh Xh 47h 30h 33h 31h 33h 0Dh
Adjust the vertical
lens shift
n=-20~+20 Pn/F
VXXS0313n 56h Xh Xh 53h 30h 33h 31h 33h nh 0Dh
Adjust the vertical
lens shift
n=-20~+20 P/F
VXXG0314 56h Xh Xh 47h 30h 33h 31h 34h 0Dh
Adjust the
horizontal lens shift
n=-20~+20 Pn/F
VXXS0314n 56h Xh Xh 53h 30h 33h 31h 34h nh 0Dh
Adjust the
horizontal lens shift
n=-20~+20 P/F
VXXG0315 56h Xh Xh 47h 30h 33h 31h 35h 0Dh 3D
0:Off
1:DLP-Link
2:IR
Pn/F
VXXS0315n 56h Xh Xh 53h 30h 33h 31h 35h nh 0Dh 3D
0:Off
1:DLP-Link
2:IR
P/F
VXXG0316 56h Xh Xh 47h 30h 33h 31h 36h 0Dh 3D Sync Invert
0:Off
1:On
Pn/F
VXXS0316n 56h Xh Xh 53h 30h 33h 31h 36h nh 0Dh 3D Sync Invert
0:Off
1:On
P/F
VXXG0317 56h Xh Xh 47h 30h 33h 31h 37h 0Dh 3D Format
0:Frame
Sequential
1:Top/Bottom
2:Side-By-Side
3:Frame
Packing
Pn/F
VXXS0317n 56h Xh Xh 53h 30h 33h 31h 37h nh 0Dh 3D Format
0:Frame
Sequential
1:Top/Bottom
2:Side-By-Side
3:Frame
Packing
P/F
VXXG0318 56h Xh Xh 47h 30h 33h 31h 38h 0Dh Tilt Angle Warning
0:Off
1:On
Pn/F
VXXS0318 56h Xh Xh 53h 30h 33h 31h 38h nh 0Dh Tilt Angle Warning
0:Off
1:On
P/F

Digital Projection E-Vision Series Specifications

General

Dimensions	Varies by model
Technology	DLP
Light Source	Laser
Light Source Life	Up to 30, 000 hours (laser)
Throw Ratio	Varies by model
Projection Size	Varies depending on lens and distance
Input Lag	Varies by model
Color Gamut	Varies by model, typically Rec.709
HDR Support	Yes
3D Support	Yes
Lens Shift	Vertical and Horizontal
Keystone Correction	Yes
Inputs	HDMI, DisplayPort, DVI, VGA
Weight	Varies by model (typically 20-50 lbs)
Power Consumption	Varies by model (typically 300-500W)
