DS5 Isolated Bipolar Constant Current Stimulator DS5 Operator's Manual 5.0

The lower section of the label contains the “MOD. RECORD STATUS” (Modification Record Status) which

indicates the build status of the unit and any modifications that have been subsequently performed to the

unit.

At the time of writing, no changes to the DS5 have caused a rise in the MOD RECORD STATUS, hence no

numbers are crossed out.

Unpacking

After unpacking the DS5 stimulator from the shipping carton, please inspect each piece for any sign of

shipping damage. Please contact the carrier and your distributor, or Digitimer Limited, immediately if there

is any damage. Do not dispose of the shipping carton, as the carrier will want to examine it in order to

process a damage claim. Digitimer Limited and their distributors insure all shipments to cover shipping

damage.

It is also advisable to keep the shipping carton in the event that the instrument needs to be returned for

service.

Supplied Accessories

The following items should have been packed with your DS5 stimulator:-



Mains (Power) Lead (Cord).



USB Connection Cable (Please refer to Chapter 4, Annex 2 before connecting).



Operator’s Manual (this document).



Test Record Sheet

Please note that the USB cable supplied is specifically for use with the DS5. USB cables from other suppliers

are NOT suitable for use with this stimulator and may result in increased EMC emissions or decreased EMC

immunity.

Optional Accessories

In order to facilitate electrode connection we offer the D185-HB4 Electrode Extension Cable. This

provides a 4.5m (14.5ft) extension of the patient output sockets (4mm shrouded) terminating in a pair (2) of

DIN 42 802-1 1.5mm “Touch Proof” sockets that are colour coded to the original sockets.

The D185-HB4 is specifically designed to meet the requirements of EN(IEC) 60601 and is suitable for use

with our D185, DS7A and DS5 stimulators.

Mains Connections

The DS5 is shipped complete with a safety tested mains lead (fitted with a suitable moulded mains plug) to

most countries.

If the mains plug supplied is not suitable please advise Digitimer of the correct plug for your country.

As it is not possible to obtain certain moulded mains plugs in the UK we will supply a mains lead with a

British plug in these cases.
