DS5 Isolated Bipolar Constant Current Stimulator DS5 Operator's Manual 5.0

View > Toolbar

Toggles display of the toolbar icons.

View > Statusbar

Toggles display of the statusbar.

Updates > Check for Software Updates...

Connects to the Digitimer update server and checks if there is an update available for the DS5 UI software.

Updates > Configure Automatic Software Update Checks...

Allows the operator to set their own software update preferences.

Updates > Check for Firmware Updates...

Connects to the Digitimer update server and checks if there is an update available for the DS5 firmware.

Updates > Import Firmware Updates...

Firmware updates can be installed from a saved file rather than directly through the internet.

Help > Online Help

Opens a PDF copy of the DS5 Operators Manual.

Help > About

Displays information about the DS5 UI software. This can also be accessed via the icon.

Meters

The meters display provides a graphical representation of some of the stimulation parameters which the DS5

monitors continuously. Displayed parameters include Peak Current, Peak Voltage, Average Low Current

(AvL), Average High Current (AvH), Pulse Energy (PE), Impedance (Z), Pulse Duration (PD).

Icons displayed within the AvL, AvH, PE and PD bar graphs indicate whether the normal or extended

output limits are enabled.

When values are within the normal limits and these limits are enabled, the bars are coloured blue. When

the extended limits are enabled, the bars turn amber when values are between the normal and extended

limits. If an enabled limit is exceeded, three events will occur:-

(i) The relevant bar will turn red.

(ii) The green or amber shield will be replaced by a red shield with a white cross .

(iii) The stimulator output will be disabled.
