Operation Manual
D0 3 S Thermal Transfer Overprinter
- 75 -
5.4 REPLACING THE REEL ROLLER
The peel roller is a wear part and should be checked regularly for damage and changed if necessary.
Each print head has a individual resistance level,
and the voltage level setting required for each is
different. A label on the print head displays the
rating for that particular one. In this case,
R=1267
This value must be entered into the controller
menu structure, or will be taken as an abuse.
From the Advance Setup screen, select the Printhead Resistance to enter the real value printed on the label.
1267
30
20
200
5
0
12
15
20
2 . Remove the worn peel roller,
replace a new one and fix it.
1. Remove the retaining screw from
the end of peel roller using a 2mm
wrench.
1267
1267
