DINGLI E-TECH ACE Series User Manual

8
www.cndingli.com
S1412HA
Items
Parameters
Items
Parameters
Maximum Working Height
51.51 ft
15.70 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
44.95 ft
13.70 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.60 ft
2.62 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.86 ft
2.09 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
4.10 ft
1.25 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
9.32 ft
2.84 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
12.27 ft
3.74 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
8.66 ft×3.67 ft
2.64 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
551 lbs
250 kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
3.5 km/h
Wheelbase
7.28 ft
2.22 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
8.69 ft
2.65 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2976 lbs
1350 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
11.7 kg/cm²
1142 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1013.1 kg/m²
9.9 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V
