DINGLI E-TECH ACE Series User Manual

56
www.cndingli.com
5.2.2.5 Height Limit
① Up Limit:
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "Enter" button, press the "Up" or "Down" button to switch to the maximum height
calibration option ("6. Up limit"). Press the "Enter" button to display the current angle sensor reading.
Press the "enable" and "up" buttons to lift the platform to the highest height (After the platform rises to
the top, it needs to be lowered slightly to reduce the wear of the cylinder), and then press the "enter"
button to save the current angle sensor reading as the highest height. Press the "Exit" button to
abandon the modification and return to the previous menu.
② Decent Delay Height:
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "Enter" button, press the "Up" or "Down" button to switch to the highest height calibration
option ("7. Down Limit"). Press the "Enter" button to display the current angle sensor reading. Press the
"enable" and "up" / "down" buttons to lower the platform to the decent delay height, and then press the
"enter" button to save the current angle sensor reading as the decent delay height. Press the "Exit"
button, press the "Exit" button to abandon the modification and return to the previous menu.
③ Outdoor Limit Height
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "Enter" button, press the "Up" or "Down" button to switch to the maximum height
calibration option ("8. Outdoor Limit Height"). Press the "Enter" button to display the current angle
sensor reading. Press the "enable" and "up" buttons to lift the platform to the maximum outdoor height,
and then press the "enter" button to save the current angle sensor reading as the outdoor limit height.
Press the "Exit" button, press the "Exit" button to abandon the modification and return to the previous
menu.
