42
3.2 Operating Instructions
Emergency Stop
Push in the red Emergency Stop button to the off position at the ground controls or the platform
controls to stop all machine functions.
Repair any function that operates when either red Emergency Stop button is pushed in.
Emergency Lowering
1 Pull the emergency lowering knob.
Operation from Ground
1 Be sure the battery pack is connected before operating the machine.
2 Turn the key switch to ground control.
3 Pull out the platform and ground red Emergency Stop button to the on position.
To Position Platform
1 At the control panel, press and hold the lift function enable button.
2 Press the platform up or down button.
Drive and steer functions are not available from the ground controls.
Operation from Platform
1 Be sure the battery pack is connected before operating the machine.
2 Turn the key switch to platform control.
3 Pull out the platform and ground red Emergency Stop button to the on position.
To Position Platform
1 Press the lift function select button.
2 Press and hold the function enable switch on the control handle.
3 Move the control handle according to the markings on the control panel.
To Steer
1 Press the drive function select button.
2 Press and hold the function enable switch on the control handle.
3 Turn the steer wheels with the thumb rocker switch located on the top of the control handle.
To Drive
1 Press the drive function select button.
2 Press and hold the function enable switch on the control handle.
3 Increase speed: Slowly move the control handle off center.
Decrease speed: Slowly move the control handle toward center.
Stop: Return the control handle to center or release the function enable switch.
Use the color-coded direction arrows on the platform controls to identify the direction the machine
will travel.
