5.2.2.2 Tilt Sensing
The vehicle is parked on a horizontal plane.
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "Enter" button, press the "Up" or "Down" button to switch to the tilt angle calibration
option ("3. Tilt sensor"). Long press the "Enter" button for 5 seconds to start automatic tilt calibration;
press the "Exit" button to return to the up-level menu.
After the inclination calibration is completed, the execution result will be displayed ("Calibration
complete!" or "Tilt sensor failure!"). Press the "Exit" button to return to the up-level menu.
During the calibration process, the overload indicator will light up.
5.2.2.3 Angle Sensing
The vehicle platform is lowered to the fully retracted position.
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "Enter" button, press the "Up" or "Down" button to switch to the tilt calibration option ("4.
Angle Sensor"). Long press the "Enter" button for 5 seconds to start automatic angle calibration; press
the "Exit" button to return to the stator menu.
After the angle calibration is completed, the execution result is displayed ("Calibration complete!"
or "Angle sensor failure!"). Press the "Exit" button to return to the sub-standard menu.
During the calibration process, the overload indicator will light up.
For example, when you replace a new angle sensor, you only need to zero the angle sensor once
and do not have to calibrate the up limit and the height of descent delay several times.
5.2.2.4 OL Descent High
Turn the chassis key switch to the ground control, press and hold the "Enter" button on the ECU
panel for 5 seconds to enter the ECU setting menu. Press the "Up" or "Down" button to switch to the
"3.Calibration".
Press the "enter" button, press the "up" or "down" button to switch to the overload drop height
calibration option ("5. OL Descent High"). Press the "Enter" button to display the current angle sensor
reading. Press the "enable" and "up" buttons to lift the platform to the overload descent height, and then
press the "enter" button to save the current angle sensor reading as the overload descent height. Press
the "Exit" button, to abandon the modification and return to the previous menu.
