DINGLI E-TECH ACE Series User Manual

9
www.cndingli.com
1.2 AC Specification
S06 ACE
Items
Parameters
Items
Parameters
Maximum Working Height
25.59 ft
7.80 m
Maximum hydraulic
pressure (functions)
180bar
Maximum Platform Height
19.03 ft
5.80 m
Tire size
Φ323×100mm
Height, stowed
Rails up
7.05 ft
2.15 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.00 ft
1.83 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.49 ft
0.76 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
6.10 ft
1.86 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
9.06 ft
2.76 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
5.48 ft×2.43 ft
1.67 m×0.74 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507 lbs
230 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.5km/h
Wheelbase
4.46 ft
1.36 m
Platform raised, maximum
0.6km/h
Turning radius (outside)
5.38 ft
1.64 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
1565 lbs
710 kg
Ground clearance
3.54 in
9 cm
Tire contact pressure
10.4 kg/cm²
1019 kPa
Ground clearance
(Pothole guards deployed)
0.63 in
1.6 cm
Occupied floor pressure
1373 kg/m²
13.5 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V
