19
www.cndingli.com
2.2 Power Unit Module
2.2.1 General Overview
S06 ACE & HA
Regarding the hydraulic and electric drive models of 0807, their function valve blocks are
different. S06ACE
For JCPT 0807 AC, its drive-motor controller is installed on the surface of the chassis.
Oil tank
ECU
Pump-motor
Filter
Valve block*
Pump-motor
controller
Relay
