59
6.2 Brake Release
HA Type
Brake release block:
1) Chock the wheels to prevent the machine from rolling.
2) Be sure the winch line is properly secured to the drive chassis tie points and the path is clear of
all obstructions.
3) Push in the black brake release knob to open the brake valve.
4) Pump the red brake release pump knob until brake released.
Towing the HA Model is not recommended. If the machine must be towed, do not exceed 3.5 km/h.
AC Type
1) Chock the wheels to prevent the machine from rolling.
2) Pull out the red Emergency Stop button on both the ground and platform controls to the on
position.
3) Enter ECU setting interface: Press & hold the “Enter” button and turn the key switch to ground
control, then enter password of “0000”.
4) Select “4. Special Mode” → “1. Brake Release”.
Towing the AC Model is not recommended. If the machine must be towed, do not exceed 4.0 km/h.
