2.2.2 ECU Overview
1 Menu escape button
9 Platform up button
2 LED readout screen
10 Red Emergency Stop button
Push in the red Emergency Stop button to
the off position to stop all functions. Pull out
the red Emergency Stop button to the on
position to operate the machine.
3 Menu up button
4 Menu down button
5 Menu enter button
11 Key switch
Turn the key switch to the platform position
and the platform controls will operate. Turn
the key switch to the off position and the
machine will be off. Turn the key switch to
the base position and the ground controls
will operate.
6 Overload indicator light
7 Function enable button
8 Platform down button
=
+
AC New version
(Highly integrated)
DC Old version
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑾
