DINGLI E-TECH ACE Series User Manual

22
www.cndingli.com
Pin definition
PIN
INPUT/OUTPUT
FUNCTION
Remark
1
OUTPUT
Forward valve
Only HA
2
OUTPUT
Reverse valve
Only HA
3
POWER
24V
4
OUTPUT
Steering right
5
OUTPUT
Steering left
6
INPUT
Pothole switch（left）
7
INPUT
Pothole switch（right）
8
OUTPUT
Lifting valve
9
OUTPUT
Lowering valve
10
POWER
GND
11
OUTPUT
Hour meter
12
COMMUNICATION
CAN L
13
OUTPUT
14
POWER
24V
15
POWER
24V
16
OUTPUT
Horn
17
OUTPUT
Speed valve
18
OUTPUT
Beacon
19
INPUT
20
INPUT
21
OUTPUT
Angle sensor reset
22
SAFETY OUTPUT
23
INPUT
Angle sensor
24
INPUT
Pressure sensor（voltage）1
25
OUTPUT
26
OUTPUT
Angle sensor power
27
POWER
24V
28
SIMULATION OUTPUT
29
INPUT
Down limit switch
30
INPUT
31
POWER
24V
32
INPUT
33
INPUT
Pressure switch
34
INPUT
Footswitch
GND
35
INPUT
36
INPUT
