DINGLI E-TECH ACE Series User Manual

11
www.cndingli.com
S0808ACE
Items
Parameters
Items
Parameters
Maximum Working Height
32.81ft
10.00m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
26.25 ft
8.00m
Tire size
Φ381×127mm
Height, stowed
Rails up
7.74ft
2.36m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.56ft
2.00m
Maximum sound level at normal operating
workstations (A-weighted)
Width
2.72ft
0.83m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14ft
2.48m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09ft
3.38m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45ft × 2.66ft
2.27m × 0.81m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95ft
0.90m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
507lbs
230kg
Drive speeds
Maximum wind speed
0
Stowed, maximum
4.0km/h
Wheelbase
6.14ft
1.87m
Platform raised, maximum
0.8km/h
Turning radius (outside)
6.89ft
2.10m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2116lbs
960kg
Ground clearance
3.94in
10cm
Tire contact pressure
10.8kg/cm²
1062.7kPa
Ground clearance
(Pothole guards deployed)
0.75in
1.9cm
Occupied floor pressure
1309.1kg/m²
12.8kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V

DINGLI E-TECH ACE Series Specifications

General

Brand	DINGLI
Model	E-TECH ACE Series
Category	Scissor Lifts
Language	English
