DINGLI E-TECH ACE Series User Manual

13
www.cndingli.com
S1012ACE
Items
Parameters
Items
Parameters
Maximum Working Height
39.37 ft
12.00 m
Maximum hydraulic
pressure (functions)
240bar
Maximum Platform Height
32.81 ft
10.00 m
Tire size
Φ381×127mm
Height, stowed
Rails up
8.17 ft
2.49 m
Airborne noise emissions
<70dB
Height, stowed
Rails folded
6.43 ft
1.96 m
Maximum sound level at normal operating
workstations (A-weighted)
Width
3.77 ft
1.15 m
Vibration value does not exceed 2.5m/s²
Length,
platform retracted
8.14 ft
2.48 m
Maximum slope rating,
Stowed position
25%
Length,
platform extended
11.09 ft
3.38 m
Maximum side slope rating,
Stowed position
25%
Platform dimensions
7.45 ft×3.67 ft
2.27 m×1.12 m
Note: Slope rating is subject to ground
conditions and adequate traction.
Platform extension length
2.95 ft
0.90 m
Maximum working slope
X-1.5°, Y-3°
Maximum load capacity
705 lbs
320 kg
Drive speeds
Maximum wind speed
28 mile/h
12.5 m/s
Stowed, maximum
4.0 km/h
Wheelbase
6.14 ft
1.87 m
Platform raised, maximum
0.8 km/h
Turning radius (outside)
7.22 ft
2.20 m
Floor loading information
Turning radius (inside)
0
Tire load, maximum
2888 lbs
1310 kg
Ground clearance
3.94 in
10 cm
Tire contact pressure
12.9 kg/cm²
1267.4 kPa
Ground clearance
(Pothole guards deployed)
0.75 in
1.9 cm
Occupied floor pressure
1258.4 kg/m²
12.3 kPa
Weight
See serial label
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
Machine weights vary with option configurations.
Controls
Proportional
AC outlet in platform
Standard
Continuous improvement of our products is a
DINGLI policy. Product specifications are
subject to change without notice or obligation.
System voltage
24V
