Battery Level Indicator
Full Low
Use the LED readout screen to determine the battery level.
How to use the Safety Arm
1 Raise the platform until the distance of the two sets of scissor at least 0.5m.
2 Lift the safety arm, move it to the center of the scissor arm and rotate up to a vertical position.
3 Lift the upper safety arm, move it to the center of the scissor arm and rotate down to a vertical
position. (for JCPT1412, JCPT1612,)
4 Lower the platform until the safety arm rests securely on the link. Keep clear of the safety arm when
lowering the platform.
Engage all safety arms before performing maintenance or repair.
Don’t engage the safety arm unless unload the platform.
How to Fold Down the Guardrails
The platform railing system consists of three fold down rail section for the extension deck and three
sections for the main deck. All sections are held in place by four wire lock pins.
1 Fully lower the platform and retract the platform extension.
2 Remove the platform controls.
3 From inside the platform, remove the two front extension deck wire lock pins.
4 Fold down the front rail assembly. Keep hands clear of pinch points.
5 Replace the two removed pins back into each side rail bracket.
6 Fold down the extension platform left rail assembly. Keep hands clear of pinch points.
7 Fold down the extension platform right rail assembly. Keep hands clear of pinch points.
8 Carefully open the gate and move to the rear step or the ground.
9 From the rear step or from the ground, remove the left rear main deck wire lock pins.
10 Fold down the left rail assembly. Keep hands clear of pinch points.
11 Replace the removed pin back into rear rail bracket.
12 Remove the right rear main deck wire lock pins.
13 Fold down the right rail assembly. Keep hands clear of pinch points.
14 Replace the removed pin back into rear rail bracket.
15 Fold down the rear rail assembly. Keep hands free of pinch points.
How to Raise the Guardrails
Follow the fold down instructions but in reverse order.
To Extend and Retract Platform
1 Press the platform lock pin pedal on the extension deck by foot.
2 Push the platform extension guardrail to extend the platform to the desired position.
Do not stand on the platform extension while trying to extend it.
