Error indicator readout
The LED readout screen displays fault codes that provide information about the
machine operating status and about malfunctions. The fault codes listed in the following
charts describe malfunctions and can aid in troubleshooting the machine by pinpointing
the area or component affected.
List of Fault Codes
Display
Description
Lift Reaction
01
System Initialization Fault
Disables All Motion
02
System Communication Fault
Disables All Motion
03
Invalid Option Setting Fault
Disables All Motion
04
Calibration Fault
Warning Only
12
Chassis Up or Down Switch ON
Disable Chassis Control
18
Pothole Guard Fault
Disable Lifting and Driving
31
Pressure Sensor Fault
Disables All Motion
32
Angle Sensor Fault
Disables All Motion
35
Pressure Sensor 2 Fault
Disables All Motion
36
Battery Drain Alarm
Drive speed limit
37
Battery Drain Shutdown
Disables All Motion
42
Platform Left Button ON
Warning Only
43
Platform Right Button ON
Warning Only
46
Platform Enable Button ON
Disable Platform Control
47
Joystick Not In Neutral
Drive speed limit
52
Drive Forward Coil Fault
Disable Lifting and Driving
53
Drive Reverse Coil Fault
Disable Lifting and Driving
54
Lift Up Coil Fault
Disable Lifting and Driving
55
Lift Down Coil Fault
Disable Lifting and Driving
56
Steer Right Coil Fault
Disable Lifting and Driving
57
Steer Left Coil Fault
Disable Lifting and Driving
59
Parallel Coil Fault
Disable Lifting and Driving
