DINGLI E-TECH ACE Series User Manual

50
www.cndingli.com
The reference value of sensors at different heights
Angle Value
(mV)
Current Type (mA)
(Take 1612HA as an example)
Voltage Type (mV)
(Take 1012AC as an example)
Signal 1
Signal 2
Signal
No-load
4300
(A little lift)
11.41
11.94
2077
3900
10.53
12.82
1838
3500
10
13.41
1703
3100
9.72
13.57
1638
2700
9.67
13.7
1619
2300
9.83
13.57
1632
1900
10.05
13.3
1690
1300
(top of 1012)
10.9
12.44
1858
1150
(top of 1612)
11.5
11.87
Full-load
4300
(A little lift)
12.58
10.82
3180
3900
12.55
10.82
2709
3500
11.45
11.94
2529
3100
11.08
12.29
2458
2700
11.08
12.29
2445
2300
11.19
12.2
2490
1900
11.56
11.83
2567
1300
(top of 1012)
12.88
10.49
2858
1150
(top of 1612)
13.74
9.61
It should be noted that although the load percentage can be viewed in real time in this interface,
when the lifting height is lower than the descent-delay height, even if the machine is overloaded, the
machine will not trigger an overload alarm.
