DINGLI E-TECH ACE Series User Manual

74
www.cndingli.com
AC Type
Code
Valve
Description
SV1
Steering
Control the left/right turn of the vehicle.
SV2
Lift up
Control the lifting action of the lifting cylinder.
RV1
Total relief valve
0807 150Bar; 0808 130Bar; 1008 160Bar; 1012 210Bar;
1212 150Bar; 1412 190Bar; 1612 220Bar.
RV2
Steering Relief
valve
0807 80Bar; 0808~1612 120Bar.
FR1
Flow control valve
Give priority to the oil supply, stabilize the oil pressure,
and make the steering more stable.
ORF1
Orifice 1
Φ1.0
ORF2
Orifice 2
Φ1.0
