9.3 LIST OF PRINT BLOCKS
LEGEND:
b indicates a space character (ASCII 32 decimal character).
UM unit of measure of the active scale (kg, bg, bt, lb).
UMD unit of measure of the database (kg, bg, bt, lb).
+ T terminator: depending on the setting of the SEtuP >> SEriAL >> tErMin “SET TERMINATOR TYPE” step of the
SET-UP environment, a CR or CRLF, LF or no terminator is added.
XXX* These blocks do not work without the alibi memory (optional).
The weight field expands from right to left, with many spaces (ASCII 32 decimal character) for completing the field length.
NOTE
- The weight and weighing values expand from from right to left, with the necessary spaces in order to complete the field
length.
- The weighing numbers are increased with each input/output weighing cycle or with each single weigh.
9.3.1 ORDER BY KIND
CODE PRINT FORMAT
GENERIC
300 PRINT END
307 DOTTED LINE -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- + T
308 PRINTS 3 CRLF
309 DATE / TIME FOR DP24/DP190 bHH:MMbDD/MM/YY + T
318 PRINTS ON PC PORT
319 PRINTS ON PRINTER PORT
320 FORCES PRINTOUT
366 DATE DD/MM/YY + T
367 TIME HH:MM + T
368 DATE TIME DD/MM/YYbHH:MM + T
369 FOLLOWING MACRO TERMINATOR SKIPS
372 HEADING 1 XXXXXXXXXXXXXXXXXXXXXXXX
in which XXXXXXXXXXXXXXXX are the 24 characters of the first line of the heading; just the entered characters
are printed, from left to right.
373 HEADING 2 XXXXXXXXXXXXXXXXXXXXXXXX
374 HEADING 3 XXXXXXXXXXXXXXXXXXXXXXXX
377 PRINTS TERMINATOR CR or CRLF or NO TERMINATOR CR or CRLF or NO TERMINATOR
378 PRINTS A SPACE b b
379 SCALE UNIT OF MEASURE UM
380 DATABASE UNIT OF MEASURE UM
392 PRINTS WEIGH ID IDb:XXX + T
In which XXX is the weigh number, from 1 to 999; only the entered characters are printed, expanding from left to
right.
410 JUST WEIGHT ID VALUE XXX
In which XXX is the weigh number, from 1 to 999; only the entered characters are printed, expanding from left to
right.
421 STANDARD KD PROTOCOL STRING
422 AF0X PROTOCOL STRING
Through the blocks 421 and 422 it is possible to print the STANDARD or AFXX serial string (see section 5.4
TRANSMISSION PROTOCOLS for the description); the terminator of the string depends on the setting of the
SEtuP >> SEriAL >>tErMin step of the SET-UP environment (CR or CRLF or no terminator).
423 PRINTS TERMINATOR CR or CRLF or NO TERMINATOR
424 RELEASES PAPER FOR TM295
425 ACTIVATES PAPER PRESENT SENSOR FOR TM295
426 ACTIVATES TIMEOUT FOR TM295
