8.2 CONFIGURATION
In order to configure the parameters, one needs to enter the SET-UP environment in the Anout step inside the SEtuP
menu:
If various scales are connected (see the nuM.SCA parameter), the number of the scale to be configured, will be requested;
the configurations within this menu must be carried out for each connected scale.
SLot SLOT SELECTION
One selects the SLOT to be used with the analogue output: SLOT 1 or SLOT2; it is possible to indifferently use either
SLOT.
ModE OPERATING MODE
AO G = analogue output on gross weight
AO n = analogue output on net weight
Once the functioning mode is confirmed, one sets the values of the analogue output useful for the calculation in the
weighing phase, of the value that the output must take on proportionally; in other words, the digital/analogue converter
values are entered (between 0 and 65535) to which corresponds a certain output value in voltage or in current.
In this configuration the instrument keys take on the following meanings (functions):
ENTER By pressing once after a value is entered, it activates the corresponding output analogue value,
(allowing the check) but the step still remains inside in case of a new modification. By pressing a
second time (on the same entered value) it confirms and exits the step.
C Allows to quickly zero the present value.
NUMERICAL KEYS Allow entering values, from right to left.
AoMA MAXIMUM VALUE
By entering this step, one sets the maximum value of the analogue output, in other words the corresponding value of the full
scale capacity. This value can be anywhere between 0 and 65535 (values of the digital/analogue converter); if a higher digit
is entered, the instrument emits a prolonged sound, after which it zeros the value just entered.
AoZE SCALE ZERO VALUE
By entering this step, one sets the analogue output value when the scale displays zero weight. This value can be anywhere
between 0 and 65535 (values of the digital/analogue converter); if a higher digit is entered, the instrument emits a
prolonged sound, after which it zeros the value just entered.
AoMi MINIMUM VALUE
By entering this step, one sets the minimum value of the analogue output. This value can be anywhere between 0 and
65535 (values of the digital/analogue converter); if a higher digit is entered, the instrument emits a prolonged sound, after
which it zeros the value just entered.
APPROXIMATE VALUES BETWEEN THE D/A CONVERTER AND ANALOGUE OUTPUT
