Dini Argeo 3590EXP Series Technical Manual

3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc
98
8.1.2 OUTPUT ON THE NET WEIGHT
The value of the analogue output grows proportionally to the net weight on the scale in relation to the value configured for
the net weight at 0 (AO ZE), and the one configured fo the net weight equal to the capacity (AO MA).
When the gross weight is equal or greater than the capacity + 9e, the output takes on the value set for AO MA, while in the
underload condition (gross weight <= -100d with approved instrument) the output takes on the value set for AO MI.
Trend examples (approved instrument)
Gross = -100d
Gross =Max. Scale Capacity + 9e
Net = Max. Scale Capacity
Gross
Gross
