3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc

7.3 COIN BOX

Connecting the COIN BOX to the 3590E

COIN BOX

“RM5 EVOLUTION”

INDICATOR

Connection to terminal block of 3590E

1 = GND

16 = GND

2 = +5VDC

3 = TX

15 = RX

4 = RX

14 = TX

To configure the coin box you must connect to your PC and install the program Clone5Pro

CONFIGURATION

Follow these STEP:

1) With the COIN BOX off set all the DIP SWITCH to ON

2) Turn the COIN BOX, so introduce the coin for 15 times; after the recognition, the COIN BOX emit a particular

double clack;

3) Put all the DIP SWITCH to OFF

4) Turn off and after turn on the COIN BOX

After you have configured the COIN BOX at the recognition of the coin you need to connect with the software “CLONE 5” to

enable the configured channel:

1) Connect the COIN BOX to the PC

2) Run the program Clone 5 and read the configuration of the COIN BOX

3) Move to the TAB relative to the programmed channel (in the example below is the 6, so the TAB Channel 1- 10)

4) Enable the Check of the configured channel and set 1,00 or on channel 6 in the form of value.
