3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc
FUNCTION OF THE KEYS IN THE SET-UP ENVIRONMENT
Allow to scroll forwards and backwards in the menu steps or in the parameters inside a step.
Allows to enter a step or confirm a parameter inside a step.
Allows to exit a step without confirming any changes made and to go to the previous level.
While entering a code, it quickly zeros the displayed value.
It allows to print the entire configuration of the set-up environment (if one is in the main menu), or
to print the configuration of the single step (if one is in the desired step).
The display shows the “PRINT” message: press ENTER to confirm or C to cancel.
Allows entering digits or characters.
The display show the current parameter and its description; generally, when one exits a step the instrument places itself on
the following step.
TO EXIT THE SET-UP ENVIRONMENT, PRESS THE C KEY MANY TIMES UNTIL THE INDICATOR SHOWS:
CONFIRM WITH ENTER TO SAVE CHANGES MADE OR PRESS ANOTHER KEY TO NOT SAVE.
