3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc
51
<< inPutS >> INPUT TEST
By pressing ENTER it’s possible to test the status of the inputs; the display will show:
in which the number on the first line identifies the input:
1 IN1
Inputs of the motherboard
2 IN2
3 IN3
Inputs of the expansion board
8 IN8
and the number each input corresponds to its status:
0 = disabled;
1 = enabled.
<< Anout >> ANALOGUE OUTPUT
If the instrument is fitted with the analogue output, through this step one can test if the values of the D/A converter (to be
entered at time of calibration) correspond with the relative values of the analogue output (in voltage or in current), see
section 6.
By pressing ENTER the display shows 0; enter a value between 0 and 65535 and confirm with ENTER; the instrument
will supply the corresponding analogue value in output.
To exit the test confirm twice with ENTER the same entered value.
<< SEr. >> SERIAL PORTS TEST
By pressing ENTER it’s possible to redirect the data received by any serial port, on other serial ports.
<< SEr.nuM >> SERIAL NUMBER
Diagnostics check for use of the manufacturer.
<< P.teSt >> PRINT TEST
With this feature you can print all print formats of the instrument. By pressing ENTER the step it is asked which format to
print. If you enter the 0 value, all print formats are printed in sequence.
<< nEt.VEr >> NET FIRMWARE VERSION
This step shows the version of the net firmware (SETH). If the SETH device was not found the message "SETH DEVICE
NOT FOUND" is displayed, otherwise the version is displayed in the form:
"NET FW VERSION"
"01.02.05.0036" (present version)
<< EU.LoG >> EVENT LOG VIEWER
The instrument stores the following types of events:
- Metric event (calibration, equalization)
- Battery event (on, off, change of power, ...)
- Keyboard event (pressed keys)
- Setup event (by default, to restore from backup, save setup, ...)
- Firmware update event (firmware update)
For each type of event the last 10 events are stored with date/time In the function you can select what type of event is
displayed and scroll the last 10 events. The F5 key is to be pressed in order to print the list.
INPUTS
1 2 3 4 5 6 7 8
0 0 0 0 0 0 0 0
