3590EKR, 3590EXP, 3590EXT, 3590 EBOX, CPWE, CPWET series indicator E-AF03_05.01_14.07_EN_T.doc
8
EARTHING EXAMPLE OF A SILO
Non weighing
structure (silo)
Weighing
structure
Load cell
U-bolt between
plate under cell
and weighing
structure (not
supplied)
Ø 4,6 – 16 mm²
earth cable
section (not
supplied)
Ø 8 – 50 mm²
earth cable
section (not
supplied)
Junction
box
