UltiMate 3000 Nano and Cap - System Installation and Application
31
No. Description Part No.
1
Nano HPLC
1 Solvent lines (analytical) 6030.2548
2 Solvent lines from degasser to proportioning valve
(set of 3 including the appropriate fittings)
6035.2540
3 Connection proportioning valve to working pump head (including fittings) 6035.2514
4 Capillary from working pump head to equilibration pump head (including fittings) 6035.3014 (standard) or 6037.3011 (biocompatible)
5 Capillary from equilibration head to outlet unit (including fittings) 6035.3014 (standard) or 6037.3011 (biocompatible)
6 Inline filter (0.5 µm) in frit holder on outlet unit 6000.0045 (standard) or 6282.0022 (biocompatible)
7 Capillary from pump to flow splitter
Long connection (system with detector)
Short connection (system without detector)
6035.2550
2
(standard) or 6037.2550
2
(biocompatible)
6035.2553
2
(standard) or 6037.2553
2
(biocompatible)
8 Capillary from flow splitter to left switching valve in flow manager 6720.0033
2
(standard) or 6021.0033 (biocompatible)
9 Trap column holder (with appropriate capillaries) and
Trap column
6720.0012
2
160454
2
10 Separation column (The column is connected directly to the switching valve.) 160321
2
11 Capillary from separation column to detector flow cell The flow cell is shipped with appropriate capillaries.
12 PEEKsil bridge from left to right switching valve in the flow manager 6720.0060
2
(standard) or 6721.0060
2
(biokompatibel)
13 Ion exchange column (SCX) 162152
2
14 Capillary from loading pump outlet unit to autosampler
Long connection (system with detector)
Short connection (system without detector)
6720.0032
2
(standard) or 6721.0032
2
(biocompatible)
6720.0031 (standard) or 6721.0031 (biocompatible)
15 Sample loop (20 µl) 6820.0018
2
(standard) or 6821.0018
2
(biocompatible)
16 Capillary from autosampler to right switching valve in flow manager 6720.0038
2
(standard) or 6721.0038
2
(biocompatible)
17 Standard needle (2.4 µl, fused silica) 6820.3010 (standard) or 6821.3010 (biocompatible)
1
The part number refers to the packing unit. For more information, contact your Dionex Sales Representative.
2
These parts are included in the 2D LC Salt Plug Kit (→ section 8.4, page 65).
To Next Page
