UltiMate 3000 Nano and Cap- System Installation and Application
42
No. Description Part No.
1
Nano/Nano
HPLC
Capillary/Capillary
HPLC
Monolith./Monolith.
HPLC
1 Solvent lines (analytical) 6030.2548
2 Solvent lines from degasser to proportioning valve
(set of 3 including the appropriate fittings)
6035.2540
3 Connection proportioning valve to working pump head (including fittings) 6035.2514
4 Capillary from working pump head to equilibration pump head (including fittings) 6035.3014 (standard) or 6037.3011 (biocompatible)
5 Capillary from equilibration head to outlet unit (including fittings) 6035.3014 (standard) or 6037.3011 (biocompatible)
6 Inline filter (0.5 µm) in frit holder on outlet unit 6000.0045 (standard) or 6282.0022 (biocompatible)
7 Capillary from loading pump (LPG-3400) to autosampler 6720.0057
2
(standard) or 6721.0057
2
(biocompatible)
8 Capillary from autosampler to FLM-3200 left switching valve 6720.0038
2
(standard) or 6721.0038
2
(biocompatible)
9 Trap column holder (with appropriate capillaries) and
Trap column
6720.0012
2
160454
2
6720.0012
2
160454
2
-------
164972
2
10 PEEKsil bridge from left switching valve (FLM-3200) to FLM-3300 switching valve 6720.0059
2
(standard) or 6721.0059
2
(biocompatible)
11 Trap column holder (with appropriate capillaries) and
Trap column
6720.0012
2
160454
2
6720.0012
2
160454
2
-------
164972
2
12 Capillary from analytical pump 1 (DGP-3600-left pump) to FLM-3200 flow splitter
Long connection (system with detector)
Short connection (system without detector)
6035.2556
2
(standard) or 6037.2556
2
(biocompatible)
6035.2554
2
(standard) or 6037.2554
2
(biocompatible)
13 FLM-3200: Capillary from flow splitter to left switching valve
Standard
Biocompatible
6720.0033
2
6721.0033
2
6720.0034
2
6721.0034
2
6720.0034
2
6721.0034
2
14 Separation column (The column is connected directly to the switching valve.) 160321
2
160295
2
16409
2
15 FLM-3200: Capillary from the separation column to the right switching valve Connect the column to the switching valve. If necessary, use the appropriate
connection parts from the respective Parallel LC kit.
16 Capillary from right switching valve (FLM-3200) to detector flow cell The flow cell is shipped with appropriate capillaries.
