Directed Electronics PYTHON 1090 - Primary Harness (H1), 12-Pin Connector; Auxiliary Harness (H2), 6-Pin Connector

© 2006 Directed Electronics—all rights reserved
18
primary harness (H1), 12-pin connector
H1/1
RED/WHITE (-) 200 mA channel 2 validity output
H1/2
RED (+) Constant Power Input
H1/3
BROWN (+) Siren Output
H1/4
EMPTY NOT USED
H1/5
BLACK (-) Chassis Ground Input
H1/6
VIOLET (+) Door Trigger Input, Zone 3
H1/7
BLUE (-) multiplexed Input, Zone 4
H1/8
GREEN (-) Door Trigger Input, Zone 3
H1/9
BLACK/WHITE (-) 200 mA domelight supervision output
H1/10
WHITE/BLUE (-) remote start activation input
H1/11
WHITE (+)/(-) Selectable Light Flash output
H1/12
Orange (-) 500 mA Armed Output
auxiliary harness (H2), 6-pin connector
H2/1
LIGHT BLUE (-) second unlock output
H2/2
WHITE/BLACK (-) CHANNEL 5 OUTPUT
H2/3
VIOLET/BLACK (-) channel 4 output
H2/4
GREEN/WHITE (-) FACTORY ALARM REARM output
H2/5
GRAY/BLACK (-) WAIT TO START INPUT
H2/6
LIGHT GREEN/BLACK (-) factory ALARM disarm output
