30
PINK/WHITE (+) second ignition output
Connect this wire to the second ignition wire in the vehicle. (See Finding the Wires You Need section.)
NOTE: For vehicles that do not have a second ignition wire, this connection is not required.
RED/WHITE (+) 12V input
Connection for high current outputs. The heavy gauge red/white wire serves the same function as the
heavy gauge red wires
remote start secondary harness (H3) wire connection guide
H3/1 BLACK/WHITE neutral safety switch input
Connect this wire to the provided toggle (override) switch as shown in figure A. Connect the other wire
from the toggle switch to the PARK/NEUTRAL switch in the vehicle. This wire will test with ground with the
gear selector either in PARK or NEUTRAL. This will prevent the vehicle from accidentally being started while
in a drive gear. This input MUST rest at ground in order for the remote start system to operate. Connected
properly the vehicle will only start while in PARK or NEUTRAL.
In some vehicles, the PARK/NEUTRAL position switch activates a factory starter lock out that will not allow
the starter to operate in a drive gear. In these vehicles, connect this wire to the toggle switch as shown in
figure B. Connect the other wire from the toggle switch to chassis ground.
IMPORTANT! Always perform the Safety Check section of this installation guide to verify that the vehicl-
cannot be started in ANY drive gear and that the override switch is functioning properly.
